Advanced Packaging Equipment

Discover our revolutionary Advanced Packaging Equipment for automated and high precision manufacturing.

Wafer Level Packaging Services

Engage with us for highly customized Wafer Level Packaging services with our line-up of edge-leading capabilities installed.


We are supplying complete plating solutions by utilizing our plating know-how for a guaranteed process transfer.




Compact in footprint yet highly flexible manufacturing machine with PacTech’s laser soldering technology.

PacTech’s laser solder jetting technology is clean, precise, and flexible. Our unique ball handling mechanism supplies a separated single solder ball into the capillary where the laser beam’s thermal energy melts the solder ball, and the solder is deposited to arbitrary positions and being reflowed immediately. It works with various solder alloys of different melting point and requires no flux therefore it is clean.

The localized heat and short pulse are generated by the laser that assures minimal thermal stress is applied on the area beyond the joined surfaces. The selective single solder ball dispensing mechanism requires no tooling for masking soldering locations, hence enables flexible soldering location and contactless soldering.

  • Fluxless

  • Mask/Stencil-less

  • Clean
  • Precision

  • Low Thermal Stress
  • 3D Soldering



Highly customizable laser assisted bonding technology for high precision and low thermal stress assembly.

Using localized laser heating mechanism, temperature can be applied selectively in the interconnection areas of interest without heating up the entire substrate up to the reflow temperature to liquefy and reflow an interconnection of a few microns. With customized bond tool and laser technology, pick-and-place and assembly reflow heating are accomplished in single step at high accuracy <5µm. Localized heat ensures reliable bonding of large dies while the in-situ reflow supports ultra-small die assembly as small as 300µm.

Our unique temperature control mechanism protects single chip or component from being over-heated and prevents substrate from warpage and repeating reflow circumstances.

  • Localized and selective heating with laser
  • Flexible laser beam shaping
  • In-situ reflow for low thermal stress
  • Customizable bond tools
  • High placement accuracy
  • Suitable for bonding materials with CTE-mismatch


Fully automated high throughput manufacturing line with PacTech’s electroless plating technology.

Our mask-less self-patterning wet chemical plating process applies Nickel, Palladium and Gold over the Aluminium or Copper bond pad on semiconductor wafers of different materials including Silicon, Silicon compound, Indium Phosphide, Lithium Tantalate etc. This layer acts as an adhesion layer, diffusion barrier, and wetting layer for the solders and wire bonds to enhance reliability and performance of various assembly and packaging such as Flip Chip and WLCSP. The wafers are loaded in a fully automated wet chemical plating line, where the wafers are handled by robot handler to go through chemical bathes which are well-controlled by in-line analysis and maintenance.

Talk to us to understand more about the unique turnkey model we offer for low to high volume production with either subcontracting services or equipment, chemical sales and technology transfer. We provide specific proprietary chemical compositions for a reproducible and reliable result, which has been proven with over 25 years of our in-house high volume manufacturing experience.

  • Low cost high throughput
  • Mask-less pad metallization
  • Fully automated dry-in-dry-out wafer processing
  • Capable of handling wafer size from 4” to 12” without tooling
  • In-line bath analysis and maintenance
  • Multi recipe management and SECS GEM interface available
Ultra - SB² 300


High accuracy ball placement technology for solder bumping in WLCSP and Flip Chip applications.

Ultra-SB2 is a fully automated solder bumping equipment integrating flux printing, ball placement, 2D inspection and wafer level rework prior to solder reflow to enable optimum bump yield on wafer up to 100%. The machine is capable of handling wafer from cassette to cassette, and the integrated 2D inspection is not only inspecting the wafer after ball placement, but also including pre- and post-placement stencil inspection to maximize solder bumping process control.

The solder balls are placed onto UBM pads of the pre-fluxed wafer and being fixed into position, enable high accuracy ball mounting especially for micro solder balls and fine pitch layouts. The wafer mounted with solder balls will be inspected again for missing, misplaced, extra solder balls and the rejects are removed and replaced prior to solder reflow. Ultra-SB2 is customizable to be integrated into existing manufacturing line via different wafer handling system to realize automatic wafer processing.

  • Capable of handling 4″-12″ wafer
  • Automated FOUP to FOUP robot handling
  • Optional integrated rework capability for optimum bump yield

  • High accuracy
  • Optional integrated flux printing and 2D AOI
  • Customizable in-line manufacturing adaptation



Electroplating, or electrochemical deposition, is the process of using electrodeposition to coat an object in a layer of metal(s) on any substrate. RDL and Copper for example, are part of this process.


Low-cost mask-less chemical deposition of various metal stacks on wafer surface to serve as intermetallic connection or to enhance product reliability and performance.

Laser Assisted Bonding

Laser assisted bonding is an interconnection method performed through the laser energy to bond two surfaces of materials together.

Solder Balling

Various solder deposition technologies to form solder bump for WLCSP and flip chip interconnects.

Wafer Level Component Assembly

Wafer level assembly by attaching of dies or various passive components on wafer surface.

Wafer Thinning

Thinning of wafer backside for dies in final packaging.

Wafer Metal Coating

Application of various metal stacks via evaporation or sputtering technologies on wafer backside for better die performance.

Wafer Dicing

High precision and accurate singulation of dies on a wafer.
